ASTM A106 Carbon Steel Pipe / API 5L Gr.B Seamless Steel Pipe

1TONS
MOQ
USD600-1500/TONS
Price
ASTM A106 Carbon Steel Pipe / API 5L Gr.B Seamless Steel Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Welding Large Diameter Pipe
DSAW: Double Submerged Arc Welded
Section Shape: Round
Thickness: As Customized
Sample: Availabled
Standard: ASTM, AISI, JIS, DIN, EN, GB
High Light:

ASTM A106 Carbon Steel Pipe

,

API 5L Gr.B Seamless Steel Pipe

Basic Infomation
Place of Origin: China
Certification: BV, SGS, ABS,
Payment & Shipping Terms
Packaging Details: Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.
Delivery Time: 7-5 working days
Payment Terms: T/T, L/C
Supply Ability: 10000tons/year
Product Description

Process :
LSAW - UO(UOE),RB(RBE),JCO(JCOE,COE)
DSAW -Double Submerged arc welded
Out Diameter : 323.9mm-1820mm(12''-72'')
Wall Thickness : 5.0 - 50mm
Length : 6 – 12m

Application : Used for low pressure liquid delivery, such as water, gas, and oil.
Standard : API 5L, ASTM 53, EN10217, DIN 2458. IS 3589, GB/T3091, GB/T9711
Certificate : API 5L PSL1 / PSL2

Steel Grade :
API 5L: GR B, X42, X46, X56, X60, X65, X70
ASTM A53: GR A, GR B, GR C
EN: S275, S275JR, S355JRH, S355J2H
GB: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555


Surface : Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement
Test : Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
Mill Test Certificate : EN 10204/3.1B

Specifications

Standard Grade Chemical Composition(max)% Mechanical Properties(min)
C Mn Si S P Yield Strength(Mpa) Tensile Strength(Mpa)
GB/T700-2006 A 0.22 1.4 0.35 0.05 0.045 235 370
B 0.2 1.4 0.35 0.045 0.045 235 370
C 0.17 1.4 0.35 0.04 0.04 235 370
D 0.17 1.4 0.35 0.035 0.035 235 370
GB/T1591-2009 A 0.2 1.7 0.5 0.035 0.035 345 470
B 0.2 1.7 0.5 0.03 0.03 345 470
C 0.2 1.7 0.5 0.03 0.03 345 470
BS EN10025 S235JR 0.17 1.4 - 0.035 0.035 235 360
S275JR 0.21 1.5 - 0.035 0.035 275 410
S355JR 0.24 1.6 - 0.035 0.035 355 470
DIN 17100 ST37-2 0.2 - - 0.05 0.05 225 340
ST44-2 0.21 - - 0.05 0.05 265 410
ST52-3 0.2 1.6 0.55 0.04 0.04 345 490
JIS G3101 SS400 - - - 0.05 0.05 235 400
SS490 - - - 0.05 0.05 275 490
API 5L PSL1 A 0.22 0.9 - 0.03 0.03 210 335
B 0.26 1.2 - 0.03 0.03 245 415
X42 0.26 1.3 - 0.03 0.03 290 415
X46 0.26 1.4 - 0.03 0.03 320 435
X52 0.26 1.4 - 0.03 0.03 360 460
X56 0.26 1.1 - 0.03 0.03 390 490
X60 0.26 1.4 - 0.03 0.03 415 520
X65 0.26 1.45 - 0.03 0.03 450 535
X70 0.26 1.65 - 0.03 0.03 585 570
